RainWise  RainWise WindLog High Capacity, Low Cost Wind Data Logger & PC Software

The WindLog is a compact, inexpensive wind data logger, designed to meet the needs of people considering the purchase of a wind turbine. While many people rely on wind maps to assist them with this purchase decision, these maps dont provide the detailed information for a specific area. The WindLog allows you to do your own accurate wind study to optimize your turbine placement and its performance, once installed. Product details 1 MB of Flash memory stores over a years worth of wind data. Operates on 3 AA Alkaline or Lithium batteries. Uses USB power when connected to a computer. USB port provides fast downloads. Free Windows software. Logs average speed, wind gust and average direction. User selectable logging intervals from 1 minute to 1 hour. The wind logger operates on three AA batteries. Battery life will depend on the environment and logging rates. Typical life should be around 6 months. Lithium batteries are recommended for cold environments. When connected to a computer the WindLog will use the USB ports power to run. This further extends the life of the batteries. SPEED Range: 0 67 meters per second (150 Mph) Accuracy: +/- 2% Sensor: 4-blade propeller Lexan UV inhibited Threshold: .45m/sec. (1 Mph) Transducer: Magnetic dry reed switch Frequency: 1 cycle per revolution DIRECTION Range: 360 no deadband Resolution: 22.5, averaged. Accuracy: +/- 22.5 Sensor: Balanced vane with a 16.5cm (6.6 inch) radius Threshold: .9 m/sec. (2 mph) at a 10 deflection. The balanced propeller is supported in stainless steel instrument ball bearings. The direction is obtained through 8 dry reed switches with no dead band. The M-AV sensor is made from UV inhibited Dupont Delrin, Lexan and stainless steel. The Mini-Aervane wind sensor is equipped with low friction race bearings. This reduces the threshold to approximately 1 mile per hour. The wind direction sensor has a 16-point resolution. Logged direction readings are averaged readings. WindSoft - Free Windows Software Package Each WindLog ships with a free Windows based application, WindSoft. The software uses a SQLite database to track and record wind information. While connected, WindSoft will update the database every minute. Downloaded data is integrated into the database. By combining both logged and real-time data the WindLog can be used both online and offline. WindSoft, can generate statistics, graphs and reports. It also can export CSV files for use with Microsoft Excel or any other application that supports CSV files. The WindLog ships with a 15 foot USB cable. This is the maximum standard USB cable length. A USB extender is available that will allow you to extend this cable to 100 feet using CAT5e network cable. A support mast is included with the WindLog. This mast can be used with the Rainwise Mono Mount, and tripod. The mast may also be attached to a support structure using U-Bolts or lag screws.
